The emergence of 　　 plasma gantry cutting machine not only promotes the rapid development of the entire cutting machine market, but also greatly increases the sales of gantry cutting machines, which promotes the development of the gantry cutting machine industry. In contrast, the gantry cutting machine , It is precisely because the gantry cutting machine has many advantages, so the laser cutting machine can be widely used, let us take a detailed understanding of the advantages of the gantry cutting machine.

　　The advantages of plasma gantry cutting machine:
　　1. Gantry beam: adopts square tube butt welding structure, with good rigidity, high precision, light weight, Features of small inertia. All welded parts have undergone vibration aging and stress relief treatment to effectively prevent structural deformation.
　　2. Longitudinal and horizontal drive: use accurate rack (7-level precision) transmission. The horizontal guide rail adopts Taiwan, imported linear guide rail, and the longitudinal guide rail adopts accurately processed special steel rail to ensure the smooth running of the cutting machine, high precision, durability, clean and beautiful appearance; planetary gear reducer is used for deceleration, which can well guarantee the accuracy and balance of movement.
　　3. Longitudinal drive frame (end frame): The horizontal guide wheels are installed at both ends, and the pressing degree of the eccentric wheel at the bottom of the drive frame can be adjusted to the guide rail, so that the whole machine can maintain stable guidance during movement. Equipped with a dust collector, which can scrape off the debris accumulated on the surface of the guide rail at any time.
　　4. The intersecting wire cutting machine adopts cylindrical coordinate coefficient control, and the number of control axes is 3 axes. With Chinese and English interface, parameter input and man-machine dialogue, fixed-angle bevel cutting, variable-angle bevel surface cutting, pipeline out-of-roundness and eccentricity compensation, online and offline automatic ignition, preheating and perforation, automatic control of cutting speed changes, etc. Features.
　　5. The CNC interface of the gantry cutting machine integrates graphics and data, and the operation is very simple: the operator only needs to input the parameters such as the radius, angle of intersection, and cutting speed of the conveying and branch pipes into the computer, and then press 'Start' button can perform automatic operations such as automatic ignition, preheating, and cutting. A reasonable cutting lead-in line is designed in the software to ensure the quality of the cutting surface, and the parameters after each cutting can be saved as a file of the same workpiece.

　　 Regarding the advantages of the plasma laser cutting machine, the above is the whole content of this article. The reason why the gantry cutting machine can be widely used today is similar to the laser cutting machine. The advantages are inseparable, if you want to get more information about the gantry cutting machine, you can pay more attention to our website.


YINGDE VENTECH INTELLIGENT EQUIPMENT CO., LTD. has created a professional team which contained with a numbers of engineers and technology experts.
YINGDE VENTECH INTELLIGENT EQUIPMENT CO., LTD. also values the time, skills, and expert opinions of our staff. We are committed to providing fair and living wages, reasonable, structured work schedules, and clear duties and spheres of rights and responsibilities for each team member.
The punching machine manufacturer INFO CENTER has significantly numerous benefits over other powder coating machine for sale systems, which makes it first choice for assembly machine manufacturers.
The first step toward VENTECH’s successful selling campaign is to understand your customers. What are their needs or desires? Why would they support your product? Even more importantly, why would they be passionate about your product?

When we use the metal laser cutting machine, we may encounter various problems. At this time, only timely treatment can avoid more serious problems. If you don’t know how to deal with thermal deformation of the material, you can refer to the detailed method in the following article.



Among the thermal cutting processing methods used by metal laser cutting machines, the effect of thermal deformation on materials is currently a major problem that affects the processing quality of metal laser cutting machines. First of all, we can give a point of view that is to use metal laser cutting The thermal cutting method of the machine cannot completely avoid the thermal deformation of the material.



Judging from the current industry application technology, whether it is water jet treatment or high-speed cutting technology, it is used to minimize the impact of thermal deformation rather than avoiding it. Therefore, this is also for many companies that are planning to purchase metal laser cutting machine equipment. Some reminders from the purchaser that manufacturers who boast that equipment can completely avoid the effects of thermal deformation need to be cautious.








Since it is impossible to completely avoid the thermal deformation of the metal laser cutting machine, what we can do is to make breakthroughs in equipment hardware design and related patented technology, and more importantly, we need equipment operators to standardize the operation process .



The metal laser cutting machine itself is used as a thermal cutting processing equipment, and during frequent processing, it will also cause structural deformation due to temperature changes. Although as a production and processing equipment, the metal laser cutting machine will adopt a series of processes in the manufacturing process to minimize the impact of thermal deformation, but as a user, in the usual use process, you should still understand this knowledge and standardize the operation. Procedures to reduce possible thermal deformation effects.



1. Reduce the heat generated by the metal laser cutting machine



The main heat source that produces thermal deformation when the internal heat of the metal laser cutting machine machine tool is heated, the heat source should be separated from the host as much as possible.



2. Improve the mechanism of metal laser cutting machine



Under the same heating conditions, the machine tool mechanism of the metal laser cutting machine also has a great influence on the thermal deformation. For example, the single-column mechanism used in CNC machine tools in the past may be replaced by a double-column mechanism. Due to the left-right symmetry, the main axis of the double-column mechanism after heating produces little deformation in other directions except for the vertical translation, and the vertical axis movement can be easily compensated by a coordinate correction.



3. Control the temperature rise of metal laser cutting machine



After taking a series of measures to reduce the heat source, the thermal deformation will be improved. However, it is usually very difficult or even impossible to completely eliminate the internal and external heat sources of the metal laser cutting machine. Therefore, the temperature rise must be controlled through good heat dissipation and cooling to reduce the influence of the heat source. The most effective method is to force cooling in the heating part of the machine tool. You can also heat the low temperature part of the machine tool to make the temperature of each point of the machine tool uniform, which can reduce the warping deformation caused by the temperature difference.



The thermal deformation of the shaft occurs in the vertical direction of the cutting tool. This can minimize the influence of the thermal deformation of the spindle on the machining diameter. In terms of structure, the distance between the center of the main shaft and the main shaft to the ground should be reduced as much as possible to reduce the total amount of thermal deformation. At the same time, the temperature rise of the headstock box should be consistent before and after to avoid tilting of the main shaft after deformation.



The ball screw in the metal laser cutting machine tool often works under the conditions of high expected load, high speed and poor heat dissipation, so the screw is prone to heat. The consequences of the thermal production of the ball screw are serious, especially in the open loop system, it will make the feed system lose the positioning accuracy. At present, some machine tools use a pre-tensioning method to reduce the thermal deformation of the lead screw. For the thermal deformation that cannot be eliminated after taking the above measures, the numerical control system can send out compensation pulses to make corrections based on the measurement results.


According to the above method, the thermal deformation of the material in the operation of the metal laser cutting machine can be handled well, and other measures can be found later.
