long lasting bending machine manufacturer for workshop
-
v s
- Ventech Automatic Machine runs an excellent, complete and effective sales and technical system. We strive to provide efficient services covering from pre-sales, in-sales, and after-sales, so as to meet customers' needs.
1. VENTECH tube bending machine is manufactured strictly complying to the LCD screen standards. Especially the resolution of its LCD screen is tested and perceived before it's used in product production.
2. The product features high energy efficiency. Using the latest electromagnetic control technology which increases its power and balances the voltage, the product achieves significant energy-saving efficiency.
3. Efficient heat transfer is one of its biggest selling points. The materials' thermal conductivity is high and has relations to their heat dissipation efficiency.
4. The product has become the preferred product in the industry, seeing the great potential of the further application.
5. Due to these features, it is extensively popular in the industry.
Company Features
1. VENTECH has become a globally renowned brand in the manufacturing field of bending machine .
2. At present, most of the automatic bending machine series produced by us are original products in China.
3. We are committed to driving our sustainability initiative by collaborating with each other, as well as with our customers, suppliers and local communities to drive positive change and, ultimately, foster a company-wide culture of sustainability. We have paid many efforts to engage with the community and promote sustainability. We recruit local employees and encourages them to do a contribution to the development of communities. Call! Undertaking corporate social responsibility has become increasingly important to our company. We attach great importance to human rights. For example, we are determined to boycott any gender or ethnics discrimination by empowering them equal rights. Call! The outstanding quality of bending machine is always our ultimate goal. Call!
Copper bar bending and cutting machine
This machine is special for processing aluminum and copper busbars used in electric
power, high/low voltage electric apparatus and busway industries. It combines punching,
cutting and bending functions together as well as some other functions such as
embossing, twisting, flatting, pressing tie-in, etc.
I Main features of copper bar bending and cutting machine
l Angle bending accuracy: +/- 1°
l Special punching mould, no pressing marks to the workpiece surface
l Special turret punch structure, with 4 punching heads, one time can punch 4 kind of holes without stopping machine to change tools
l Cutting device adopts patent double-column structure, smooth cut, no waste, no burr
l Double worktable for bending station, real separate working
l PLC control bending, bending angle can be pre-set and saved
II Main technical data of copper bar bending and cutting machine
l For punching:
Max. punching pressure: 300kN
Hole diameter: 4.3-25mm
Max. thickness: 12mm
Max. width: 160mm
Punching heads: 4 sets mounted on the machine (from 4.3~25mm)
l For cutting:
Max. cutting thickness: 12mm
Max. cutting width:160mm
l For bending:
Max. bending pressure: 300KN
Max. bending width:160mm
Max. bending thickness: 12mm
Equipped with two bending tools: R5 and R10
l For vertical bending:
Max. bending width: 120mm (10mm thick copper)
Min. bending angle: 90°
l Dimension: 1700 x 1350 x 1500mm
l Weight: about1390kg
l Main driving motor power: 4kW x 3
III Main configuration of copper bar bending and cutting machine
3.1 Main driving motors: from Taiwan
3.2 Oil pumps: from Taiwan
3.3 Electromagnetic valves and overflow valves: from Taiwan
3.4 Relays: Schneider
3.5 Contactors: Schneider
3.6 Other electric parts: from China
3.7 PLC: Panasonic from Japan
3.8 Touch screen: 7” big size from domestic
IV Accessories of copper bar bending and cutting machine
l Punching moulds: 8 sets (sizes can be selected)
l Cutting blade: one piece
l Horizontal bending moulds: two sets
l Vertical bending moulds: two sets
l Embossing mould: one set
l Tool kit: one
l Foot switches: 3 pieces
We Nantong Zhenhuan Trade Co., Ltd. is certified by TUV, BV, SGS, good reputation and
credit. We can provide you not only good machines but also good after-sale service. We
have 14 years trading experience.
